MS525AL metal tire valve
Engineered specifically for high-speed alloy wheel applications, the MS525AL Aluminum snap-in tubeless valves reduce unsprung rotational weight while maintaining absolute high-pressure integrity. We machine the main body in-house from premium automotive-grade aluminum on our multi-axis CNC centers, ensuring exact-tolerance thread pitches and a flawless mechanical fit. Backed by severe-temperature EPDM sealing grommets and 100% automated pre-shipment leak testing, the MS525AL delivers mathematically verified, corrosion-resistant airtight performance for Tier-1 automotive assembly requirements.
| MODEL NO. | RIM HOLE | EFF.LENGTH (MM) | GROMMET | WASHER | NUT | CAP | PACKAGE |
| MS525S | 11.5 (.453″ DIA) | Φ17.5×41.5 | RG9,RG54 | RW15 | HN6 | FT | 50 pcs/bag, 10 bags/case |
100% Automated Leak Testing
ETRTO compliant with defect rates strictly capped <50 PPM.
VCI Anti-Oxidation Logistics
Vacuum-sealed B2B packaging & ISPM-15 fumigated pallets.
Direct Factory OEM/ODM
Custom CNC dimensions & proprietary alloy machining available.
Fortune metal tire valve: the engineering advantage
We manufacture OE-quality metal tire valves strictly under ISO/TS16949 accreditation, covering everything from high-pressure passenger snap-ins (TR600HP series) to heavy-duty large-bore commercial truck valves (TRJ650 series). By physically controlling the CNC machining and rubber formulation on our own factory floor, we completely eliminate the catastrophic failure points common in low-end aftermarket metal valves.
premium copper & aluminum (zero zinc alloy)
Whether we are engineering a straight TR416 clamp-in valve (strictly machined to a Φ18.5x40 mm external dimension for .625" rim holes) or a heavy-duty TR-618A agricultural valve (maintaining an exact 15.9 mm solid base), we machine the main bodies exclusively from premium copper rods and aerospace-grade aluminum. We strictly prohibit the use of zinc alloy main rods in our facility. Zinc alloy valves suffer from poor material stability, causing them to crack, age, and catastrophically lose sealability under continuous radial stress. Furthermore, we completely reject the aftermarket cost-cutting practice of using lower copper content, reducing critical external dimensions by fractions of a millimeter, or drilling larger bottom holes to save material. By physically maintaining 100% of the engineered metal wall thickness, we mathematically guarantee our valves can sustain extreme operational loads without structural deformation.
in-house CNC threads & precision truck bends
A metal valve relies entirely on mechanical tolerances to prevent air bypass. From the internal core threads of our MS525AL aluminum valves (machined precisely to a Φ17x42 mm external dimension using exact-tolerance HN9 hex nuts for .453" rim holes) to the complex multi-axis bends of our V3.20 metric truck series (such as the exact 27° bend on the Φ16x115 mm V3-20-6), we do not rely on cheap, inaccurate casting. Every metal stem and hex nut is physically cut on our internal CNC processing machines. This hardware-driven control creates mathematically high-precision sizes and smooth mating surfaces, physically eliminating the scratches and surface blemishes that cause inferior valves to leak at the rim hole.
international high-standard EPDM components
The rubber component on a metal valve—whether it is the molded base of a TR600HP locking into a .453" rim hole (strictly rated for a maximum cold inflating pressure of 100 PSI / 720 kPa at room temperature) or the heavy-duty RG60 sealing O-ring on a commercial V3.20 truck valve—is your ultimate air barrier. We formulate our sealing components using international high-standard EPDM rubber. We categorically reject inferior natural rubber, which easily ages in the air and fractures under mechanical stress during automated installation. Combined with our premium 9002# high/low-temperature resistant valve cores, our in-house EPDM formulation guarantees absolute sealability and material stability across extreme temperature bandwidths from -54°C to +150°C.
Fortune metal tire valve applications
Our metal tire valves deliver absolute structural integrity and guaranteed air retention for the most demanding industrial, commercial, and high-performance applications. Engineered specifically to withstand extreme tire pressures, high-speed centrifugal forces, and severe operational temperatures, these valves provide guaranteed OE-level fitment and long-term durability. We manufacture precise sealing solutions that integrate directly into heavy-duty operations across three core vehicle sectors.
commercial fleets & heavy-duty trucks
high-performance passenger vehicles
agricultural & off-the-road (OTR) machinery
Why Partner with Fortune for Metal Tire Valves
Backed by 30 years of dedicated manufacturing expertise (Est. 1996), Fortune operates as an ISO/TS 16949:2018 and TÜV SÜD certified direct manufacturer. We do not simply assemble sourced components; we engineer our entire range of metal tire valves—from high-pressure passenger series to heavy-duty commercial truck metal tire valves—from the ground up. By centralizing a 30+ engineer R&D team, 100% in-house CNC processing, and premium copper/EPDM formulations within our facility, we physically eliminate the high-pressure leakage risks common in low-end aftermarket alternatives. We deliver a verified, fact-driven B2B supply chain built for high-volume global execution.
dedicated metal tire valve engineering & CNC innovation
All metal tire valve product development and structural design operations are executed directly by our professional team of over thirty experienced engineers and technicians. Guided by our core principle to “develop with technology,” this team continuously scales our high-pressure metal tire valve production capacity—yielding up to 5 Million units monthly. By integrating over 100+ advanced automated CNC processing machines directly into our assembly lines, we mathematically guarantee a strict machining tolerance of ±0.01 mm for every valve thread and hex nut, ensuring absolute precision and airtight fitment.
ISO/TS 16949 certified metal tire valve production
Our entire metal tire valve manufacturing facility is governed by strict ISO/TS 16949:2018 and TÜV SÜD quality management systems. We do not rely on random batch sampling; 100% of our metal tire valves undergo severe physical testing, including automated high-pressure air leak tests up to 130 PSI / 900 kPa and Neutral Salt Spray (NSS) corrosion testing for up to 72 – 96 hours to guarantee OE-level durability. For high-volume B2B orders, manual counting is obsolete. Our packaging lines utilize advanced automated precision weighing systems accurate to ±0.1 grams, mathematically guaranteeing absolute counting accuracy (exactly 100 pcs/box) before any container is shipped.
high-volume manufacturing & port logistics
Operating out of a highly advanced 25,000-square-meter manufacturing facility located just 45 kilometers from Ningbo Port—the most vital port city in China’s Yangtze Delta—we possess the robust logistical infrastructure required to execute rapid, high-volume metal tire valve exports. This strategic proximity allows us to cut domestic inland transit to under 2 hours, ensuring strict and stable delivery lead times of 15 to 25 days for bulk full container load (FCL) orders directly from the factory floor to your designated global facility.
global OEM servicing & localized support
Our engineered metal tire valves are fully integrated into the supply chains of over 300 OEMs and Tier-1 aftermarket customers across 65 countries in the Americas, Europe, Japan, Asia, and Oceania. To bypass cross-border communication delays and provide superior, localized support for our partners, we strategically established direct warehouses and corporate offices in North America in 2014. By maintaining a constant local inventory of over 2 million metal tire valves, we guarantee direct 24 to 48-hour local dispatch for our North American partners, delivering factory-direct pricing with zero international shipping delays.
more metal tire valves you might also like
FAQs about Fortune metal tire valve
What types of metal tire valves can Fortune supply?
We supply a wide range of metal tire valves, including clamp-in tire valves, tubeless tire valves, TPMS-compatible valve stems, and customized valve solutions. Our products are suitable for passenger cars, commercial vehicles, trucks, trailers, motorcycles, and other automotive applications.
Can Fortune customize metal tire valves according to customer requirements?
Yes. We provide OEM and ODM services for bulk buyers. Customization options include valve dimensions, materials, surface finishes, logo marking, packaging, and product specifications to meet different market and vehicle requirements.
How does Fortune ensure the quality and reliability of metal tire valves?
We apply strict quality control throughout the manufacturing process, including incoming material inspection, dimensional testing, air leakage testing, assembly inspection, and final performance checks. Each batch is inspected to ensure stable quality and reliable sealing performance.
What is the MOQ and lead time for bulk orders?
The MOQ depends on the product model and customization requirements. For standard metal tire valves, Fortune can support flexible bulk orders. Standard production usually takes around 15–30 days, while customized projects may require additional time for tooling, sampling, and approval.
What materials and finishes are available for Fortune metal tire valves?
Our metal tire valves are available in high-quality materials such as brass, aluminum alloy, and stainless steel. Different surface treatments, including chrome plating, nickel plating, and customized finishes, can be provided according to customer requirements.
